DL24Max150W Battery Capacity Tester, Electronic Load Tester Supports Power Expansion Mobile Phone Networking Measurement and Control Automatic Charge and Discharge Aging Test (Host)

Parameter Brand: vastarry Model: DL24MAX Test voltage: 2~200V Working current: 0.2~25A Discharge power: voltage X current <150W Constant load regulation: +/-3%+3 bytes Firmware upgrade: WiFi network upgrade The fan is automatically turned on: the temperature is below 52°C The fan automatically shuts off: the temperature is below 42°C Various functions Mobile phone smart life APP networked remote control and remote measurement; High-definition 2.4-inch TFT large color screen display of charging and discharging curve; Automatic charging and discharging battery capacity distribution curve function; Nine operating modes of the host; Encoder knob adjustment; Digital constant current control; Four-tube synchronous discharge safety design; With timed discharge and settable stop voltage; true four-wire, Measure zero line loss; The voltage and current are accurately calibrated when leaving the factory; Wide voltage 200V wide current 25A settings; WiFi networking design; Firmware update lifetime free upgrade function.

• Mobile APP, WIFI network remote control Remote measurement: 9 working modes: constant current mode, constant voltage mode, constant power mode, constant resistance mode, charge-discharge-charge mode, charge-discharge-charge-discharge-charge mode, （charge function requires optional charging module), power measurement mode, resistance measurement mode, line measurement resistance mode, etc. to meet different measurement needs
• High-definition 2.4-inch screen displays the charging and discharging curve: The whole process of automatic charging and discharging aging test is suitable for charging and discharging capacity test of various batteries, measuring various DC power supplies, lithium batteries, chargers, DC power adapters, mobile power supplies, data cables, etc. Intelligent one-button automatic detection of line resistance, detection of DC power supply, and detection of battery internal resistance
• 150W high power 4 core synchronous discharge The multi-tube current is evenly divided, and the synchronous discharge technology is adopted.It can work stably for a long time with a larger current under low voltage and high current,At the same time, the high-voltage discharge has also been improved by a breakthrough, and the overall technical index performance of the device has reached a higher leap.
• The discharge power can be freely spliced, and the playability is strong: 150W/300W/450W/600W variety of splicing, to meet various needs, add expansion interfaces around the load host, purchase power expansion modules, connect with the host, simply set software and hardware data, and can freely splicing various power sizes, the power of a single module is 150W
• Meet the measurement of small capacity batteries Increase the thickness and automatic constant current gear setting to meet the needs of users to test small capacity when setting the low current constant current mode, and add 10mA gear and automatic automatic gear selection in the background to meet the needs of batteries of different capacities. Accurate testing of current discharge
